7 Ton Mining Electric Trolley Locomotive

The 7 Ton Electric Trolley Locomotive has 2 kinds of working rated voltage: 250V or 550V. It applies primary driving way speed control of resistance IGBT or VF type. Main features include: short wheel base high sitffness body and good shickproof

CJY10 Ton Underground Mining Trolley Locomotive
The 7 Ton Electric Trolley Locomotive has 2 kinds of working rated voltage: 250V or 550V. It applies primary driving way speed control of resistance IGBT or VF type. Main features include: short wheel base high sitffness body and good shickproof performacee.
The braking type is mechanical or electric braking or air braking safe and reliadble.
The carrying loading capacity of 7 Ton trolley locomotive could up to 70 ton.

Motor power: 21kw *2
Voltage :250 v or 550v
Track gauge: 600.750.762.900 or as required.


Locomotive Avantage Please ClickLocomotive Advantages.

Operation video




7ton Trolley Locomotive

Model

CJY7/6、7、9G(B)(P)

Adhesive / total weight (t)

7t

Track gauge (mm)

600、762 or 900mm

Traction

13.05kN

15.09kN

Max. Traction (KN)

17.2kN

Speed

11km/h

Direct Voltage

250V

550V

motor power

21Kw×2

24kW×2

Dimensions

Length

4550mm

Width

1050、1212 or 1350mm

Height

1600mm

Wheel Base

1100mm

Wheel Diameter

Φ680mm

Operational height of current-controller

1800~2200mm

Min Curve radius (m)

7m

Controller

Resistance or IGBT

Braking method

Mechanical Brake
