CJY10/6, 7, 9GB 10 Ton Mining Electric Trolley Locomotive

10 Ton Mining Electric Trolley Locomotive the model is CJY10/679GB. It has 4 options: normal type thicken lateral plate type added sails type and 2 motors type. The working rated voltages include 250v and 550v Main features include:short wheel

Send Inquiry →
CJY10 Ton Underground Mining Trolley Locomotive
10 Ton Mining Electric Trolley Locomotive the model is CJY10/679GB. It has 4 options: normal type thicken lateral plate type added sails type and 2 motors type.
The working rated voltages include 250v and 550v Main features include:short wheel base and high stiffness of locomotive body.
With Application of new-type buffer the shockproof performance is good with big cushion angle.

Motor power: 24kw*2 or 30kw*2
Track gauge: 600.762.900 or as required
Carrying capacity: 100 Ton
Voltage:250V or 550V

Locomotive Avantage Please Click: Locomotive Advantages.

Operation Video


Hot Tags: mining locomotive  |   battery locomotive  |   trolley locomotive  |   electric rake winch  |   pneumatic Rock loader  |

←5 Ton Mining Electric Trolley Locomotive

CJY14/6,7,9GB 14 Ton Mining Overhead Electric Locomotive→

Related Product

10ton Trolley Locomotive

Model

CJY10/6、7、9G(B)(P)

Adhesive / total weight (t)

10t

Track gauge (mm)

600、762 or 900mm

Traction

13.05kN

18.93kN

Max. Traction (KN)

24.5kN

Speed

11km/h

Direct Voltage

250V

550V

motor power

24Kw×2

30kW×2

Dimensions

Length

4550mm

Width

1050、1212 or 1350mm

Height

1600mm

Wheel base

1100、1220mm

Wheel Diameter

Φ680mm

Operational height of current-controller

1800~2200mm、2000~2400mm

Min Curve radius (m)

7、10m

Controller

Resistance or IGBT

Braking method

Mechanical Brake
