Pneumatic Type Mucking Machine

Product Description Z series rock loader( Mucking Machine ) is a light-duty loading equipment for rail-wheel type underground tunneling and stope. It has compact structure strong adaptability reliable work easy operation and maintenance. It can be

CJY10 Ton Underground Mining Trolley Locomotive
Product Description
Z series rock loader(Mucking Machine) is a light-duty loading equipment for rail-wheel type underground tunneling and stope. It has compact structure strong adaptability reliable work easy operation and maintenance. It can be loaded on general rocks large stones iron ore granite and other metal or non-metal mines and can load up to 500MM with a slope of 100m~400m the loading efficiency is the highest and it is suitable for horizontal roadways in various mines (gradient ≤8). The machine is a bucket type front loading and rear unloading self-propelled and its power source is pneumatic and electric.

Operation Video



Hot Tags: Pneumatic Type Mucking MachineChina manufacturers suppliers factory customized price
Specification Table
Model Z-17AW Z-20AW Z-30AW ZQ-26
Loading capacity m³/h 20-30 30-40 50-60 40-50
Loading area m³ 0.17 0-20 0.3 0.26
Loading width m 1.7 2 2.2 2.7
Track gauge mm 500600762 or 900
Power Motor Motor Motor Wind motor
Walking power kw 10.5 10.5 15 10.5
Lifting bucket power KW 10.5 13 15 15
Unloading height mm 10.5 1360 1370 1250
Dimension mm Length  2120 2480 2620 2440
Width 1011 1380 1320 1380
Height 1920 1460 1545 1500
Weight 3760 3700 4600 2700
