Bucket-tipping mine car/Wagons

The bucket-tippingmine car /Wagons is a narrow-gauge railway transportation vehicle for transporting coal ore ballast and other bulk materials in the mine. Generally it must be tractby a locomotive or a winch. According to different structures and

CJY10 Ton Underground Mining Trolley Locomotive

The bucket-tipping mine car /Wagons is a narrow-gauge railway transportation vehicle for transporting coal ore ballast and other bulk materials in the mine. Generally it must be tract by a locomotive or a winch.
According to different structures and unloading methods they are divided into four categories: bucket-tipping mine car fixed mine car single-side curved rail dumping mine car and bottom-dumping mine car.

The main features of the bucket-tipping mine car:
The bucket-tipping mine car does not need any auxiliary facilities can automatically flip left and right is flexible and light.
The frame is a metal structure which can withstand the traction force ultromotivity collision force between mine cars and rail impact force;
This type of mine car has the advantages of firm structure beautiful appearance reliable performance flexible and stable operation etc.
The frame of the mine car adopts a riveted welding structure which reduces the influence of gravity on the mine car and increases the service life of the mine car.
The mine car is guaranteed to run smoothly whether in a bend or a straight.
This series of mining wagon are widelyused for underground and surface coaltransportation in coal minesiron ore phosphate mines etc. It iscommonly used transportation equipment such as coal mines.



Operation video



Shipment and one site details








Technical performance table of bucket-tipping mine car

ModelVolume(m3 Load(T)Gauge(mm)Wheel Base(mm)Wheel Diameter (mm)Traction force (KN)Traction Height(mm)Overall Size(LxWxH)Weight(kg)
KFU0.55-60.551.3600500300603201552*850*1150700
KFU0.75-60.751.88600600300603201700*980*1250740
KFU1.0-612600650300603201910*1070*1320760
KFU1.2-6 1.23600650300603202060*1150*1300610
