2.5 Ton Battery Powered Locomotive with hydraulic brake

2.5 Ton Battery Powered Locomotive with hydraulic brake will be more safer when it put into application. This locomotive is under the requirements of our South America clients.

CJY10 Ton Underground Mining Trolley Locomotive

Technical Specification

Model CTY2.5/6、7、9G(B)
Dead weight 2.5t
Track gauge 600、762 or 900mm
Traction force 2.55kN
Max traction force 6.13kN
Speed 4.54km/h
Battery device Lithium battery 51.2v 300ah
Lead acid battery 48V330AH
Motor power 3.5kW×1
Dimensions Length 2330mm
width 914、1076 or 1212mm
Height 1550mm
Wheelbase 650mm
Wheel diameter Φ460mm
Min turn radius 5m
Controlling way Resistance or IGBT chopper
Brake way Mechanical brake




2.5t battery locomotive 1.jpg

shipment and site 1.jpg
