Axial Flow Main Ventilator Fan For Mining

FBCZ series mine ground flameproof extraction type axial flow main ventilator is designed and manufactured by our company that using bending-sweep combination orthogonal technology. The ventilator is a new type of high-efficiency energy-saving main v

CJY10 Ton Underground Mining Trolley Locomotive

Axial Flow Main Ventilator Fan For Mining

FBCZ series mine ground flameproof extraction type axial flow main ventilator is designed and manufactured by our company that using bending-sweep combination orthogonal technology. The ventilator is a new type of high-efficiency energy-saving main ventilator with a wide range of uses. The design fully considers the ventilation network coefficients of small and medium-sized coal mines and its performance has reached the international leading level.

Scope of application: It is suitable for the large-volume mines currently dominated by comprehensive mining machinery and other factories and mines that use ventilators for metal mines and chemical mines.

We have been sold this type of flame-proof Ventilator Fan to many countries such as VietnamAfricaRussiaSouth American and so on.

We could provide design and customization according to your Mine Environment.

Application Photos of our Mine FBCZ Explosion-proof Ventilator Fans



Hot Tags: axial flow main ventilator fan

Technical Parameters

Series name Machine number Motor model Motor Power(kw) High-efficiency area Compared to A sound levels
db(A)
Air volumem2/s) Static pressurepa ≤35
FBCZ-4-No n=1450r/min 8 YBF132S-4 5.5 3.6-8.9 110-580 ≤35
9 YBF160M-4 11 4.6-12.8 130-710 ≤38
10 YBF160L-4 15 6.7-17 150-920 ≤38
11 YBF200L1-4 30 9.2-23.3 190-1100 ≤38
12 YBF225M-4 45 11-31 220-1350 ≤38
13 YBF250M-4 55 13.8-38 250-1600 ≤38
FBCZ-6-N
on=980r/min
10 YBF160M-6 7.5 *4-12 75-400 ≤38
11 YBF160L-6 11 *6-15 85-510 ≤38
12 YBF180L-6 15 *8-21 95-590 ≤38
13 YBF200L2-6 22 *11-27 115-690 ≤38
14 YBF225M-6 30 12.5-33 145-800 ≤38
15 YBF280S-6 45 15-40 170-900 ≤38
  16 YBF280M-6 55 20-48 195-1100 ≤38
17 YBF315S-6 75 21-57 205-1200 ≤38
18 YBF315L1-6 110 26-70 215-1350 ≤38
19 YBF315L2-6 132 31-80 230-1550 ≤38
