ZBQ-15 Motor

ZBQ-15 Motor is applied in the 8 Ton battery locomotive the model number is CTY8/679GB the dual transmissions way. It is could applied in the place with explosion-gas or great humidity. Technical specification table Motor Power 15Kw Voltage 130V

CJY10 Ton Underground Mining Trolley Locomotive

ZBQ-15 Motor is applied in the 8 Ton battery locomotive the model number is CTY8/679GB the dual transmissions way.
It is could applied in the place with explosion-gas or great humidity.

Technical specification table

Motor Power 15Kw
Voltage 130V
Current 136A
Rotating speed 1060r/min
Max Current 272A
Max Rotating 2230r/min
Structural type Horizontal
Working rating S2-60MIN
Excitation mode Series
Insulation grade F or H
Type of cooling IC40
Weight 362KG
