Wheel Type Pneumatic Shovel Rock Loader performance Characteristics: Downhole direct unloading bucket type pneumatic rock loader. Its purpose is to put the rock down into the tub.
Wheel Type Pneumatic Shovel Rock Loader performance Characteristics: Downhole direct unloading bucket type pneumatic rock loader. Its purpose is to put the rock down into the tub. To achieve the mechanization of loading work, thereby reducing the labor intensity of workers, improve productivity. Wheel Type Pneumatic Shovel Rock Loader is mainly used for the horizontal exploration of pneumatic equipment, roadway, or tunnel roadway can also be used for cavern excavation or mine loading work.
Shipment and one site details
| Model | Model | |
| Loading capacity | 100m3/h | 70m3/h |
| Loading area | 0.45m3 | 0.3m3 |
| Walking power | 20HP*2 | 9kw*2 |
| Maximum air consumption | 17.6m3/min*2 | 17.6 m3 / min×2 |
| Working pressure | 4.21-7.03kg/cm2(60-100psi) | 4.21-7.03kg/cm2(60-100psi) |
| Rising motor | 25HP*2 | 15kw |
| Maximum air consumption | 20m3/min | 20m3/min |
| Working pressure | 4.21-7.03kg/cm2(60-100psi) | 4.21-7.03kg/cm2(60-100psi) |
| Walking speed | 1.81m/s | 1.81m/s |
| Tire type | solid tire | solid tire |
| Rising height | 2600mm | 2380mm |
| dump width | 1200mm | 1200mm |
| Unloading height | 1500mm | 1400mm |
| Unloading distance | 457mm | 450mm |
| Machine length | 2800mm | 2600mm |
