Our 55Q 15kg/m Railroad Steel Rail, 33lbs Steel Rail for Underground Mining, a reliable solution for mining and transportation needs. This light rail is specifically designed for use in mining construction and rail transport applications.
Production Introduction
Our 55Q 15kg/m Railroad Steel Rail, 33lbs Steel Rail for Underground Mining, a reliable solution for mining and transportation needs. This light rail is specifically designed for use in mining construction and rail transport applications. It provides sturdy support for mining electric locomotives, mine carts, and other track transport vehicles, ensuring smooth and efficient operations. Crafted from high-quality Q235 or 55Q steel, this rail offers durability and strength, making it ideal for heavy-duty use in demanding mining environments. Choose our light steel rail for dependable performance and seamless transportation solutions in your mining operations.
←Chinese Standard 55Q 12kg/m Steel Rail, 26lbs Railway Track for Mining
High Quality 55Q 18kg/m Steel Rail, 39lbs Railway Track for Locomotive Running→
| Name | Model | Sectional Dimension(mm) | Theoretical weight | |||
| Height | Bottom Width | Head Width | Web Thickness | |||
| Light Rail | 8Kg/m | 65.00 | 54.00 | 25.00 | 7.00 | 8.42 |
| 12Kg/m | 69.85 | 69.85 | 38.10 | 7.54 | 12.20 | |
| 15Kg/m | 79.37 | 79.37 | 42.86 | 8.33 | 15.20 | |
| 18Kg/m | 90.00 | 80.00 | 40.00 | 10.00 | 18.06 | |
| 22Kg/m | 93.66 | 93.66 | 50.80 | 10.72 | 22.30 | |
| 24Kg/m | 107.00 | 92.00 | 51.00 | 10.90 | 24.46 | |
| 30Kg/m | 107.95 | 107.95 | 60.33 | 12.30 | 30.10 | |
| Heavy Rail | 38Kg/m | 134.00 | 114.00 | 68.00 | 13.00 | 38.733 |
| 43Kg/m | 140.00 | 114.00 | 70.00 | 14.50 | 44.653 | |
| 50kg/m | 152.00 | 132.00 | 70.00 | 15.50 | 51.514 | |
| 60Kg/m | 176.00 | 150.00 | 73.00 | 16.50 | 60.800 | |
| 75Kg/m | 192.00 | 150.00 | 75.00 | 20.00 | 74.640 | |
| UIC54 | 159.00 | 140.00 | 70.00 | 16.00 | 54.430 | |
| UIC60 | 172.00 | 150.00 | 74.30 | 16.50 | 60.210 | |
| Lifting Rail | QU70 | 120.00 | 120.00 | 70(76.5) | 28.00 | 52.8 |
| QU80 | 130.00 | 130.00 | 80(87) | 32.00 | 63.69 | |
| QU100 | 150.00 | 150.00 | 100(108) | 38.00 | 88.96 | |
| QU120 | 170.00 | 170.00 | 120(129) | 44.00 | 118.1 | |
