ZQ-18-5 traction DC motor for CJY6 trolley locomotive

ZQ-18-5 mining DC motor main purpose and scope of application1.Main useThe motor is placed inside the CJY6 trolley locomotive and should be able to operate normally in the following environments:

CJY10 Ton Underground Mining Trolley Locomotive

ZQ-18-5 mining DC motor main purpose and scope of application

1.Main use

The motor is placed inside the CJY6 trolley locomotive and should be able to operate normally in the following environments:

a) The altitude does not exceed 2000m;

b) The maximum air temperature in the shade shall not exceed 40℃, and the minimum air temperature shall not be lower than -25℃;

c) The average maximum relative humidity of the wettest month is not higher than 90% (the monthly average minimum temperature of the same month is not higher than 25℃);

d) The air contains explosive gas mixture of coal dust and gas and air.

motors 1.jpg

motors 2.jpg

motors 3.jpg

motors 4.jpg

motors 5.jpg

motors 6.jpg

motors 7.jpg

shipment and site 18.jpg



Hot Tags: ZQ-18-5 Dc motor  |   DC motor  |   traction motor  |   24kw dc motor  |   dc motor for trolley locomotive  |
Motor Power18Kw
Voltage250V
Current58A
Rotating speed480r/min
Max Current116A
Max Rotating1400r/min
Structural typeHorizontal
Working ratingS2-60MIN
Excitation modeexcitation
Insulation gradeF
Type of coolingIC40
Weight322KG
