Dual Power Electric Locomotive Battery Trolley hybrid

A trolley battery dual Power locomotive is a device that can be powered by two sources of power. When the locomotive is running in the roadway with overhead lines, the power supply can be directly supplied by the overhead lines, and when running in the roadway without the overhead lines, the battery power supply device can supply power.

CJY10 Ton Underground Mining Trolley Locomotive

trolley battery dual Power locomotive is a device that can be powered by two sources of power. When the locomotive is running in the roadway with overhead lines, the power supply can be directly supplied by the overhead lines, and when running in the roadway without the overhead lines, the battery power supply device can supply power. There is an automatic charger on the locomotive, which can automatically charge the on-board battery at any time by using the overhead power supply. It can be directly entered into the excavation roadway or Shimen with biogas and no overhead lines from the horizontal road, and can work in the area such as the trough, or directly into the high biogas level from the industrial square production field (coal preparation plant or research stone mountain), No need to change locomotives. Therefore, the production process and transportation links can be simplified, and the transportation efficiency can be improved. It also has the characteristics of large traction force, high speed, good climbing performance, safe and flexible use of the overhead electric locomotive.



Shipment and one site details

7o10t trolley locomotive 2 s.jpg

8o12t battery locomotive 1.jpg

shipment and site 16.jpg

shipment and site 13.jpg

shipment and site 11.jpg

shipment and site 2.jpg






No Information

No Information

The dimensions or techinical specification can be adjusted.

Weight9t
Track gauge600mm
wheel diameter630mm
pantograph Height1.8~2.5m
Dimensions4690X1060X1600mm
Traction force9.5kN
Speed for trolley type8.6km/h
Speed for battery type8km/h
Trolley Voltage250V or 550v
Battery voltage120V or 275v
Battery capacity330
Traction height430,320
Min turn radius8m
