The 14 Ton Overhead Trolley Locomotive is designed for big mining, the model is CJY14/6.7.9GB The max loading capacity of this locomotive could up to 140Ton Motor Power:52*2 Track Gauge:600.750.762,900 or as required Controller: Resistance, IGBT or AC
The 14 Ton Overhead Trolley Locomotive is designed for big mining, the model is CJY14/6.7.9GB
The max loading capacity of this locomotive could up to 140Ton
Motor Power:52*2
Track Gauge:600.750.762,900 or as required
Controller: Resistance, IGBT or AC frequency
Voltage:250V or 550V
Locomotive Avantage Please Click: Locomotive Advantages.
Operation Video
Shipment and one site details
14ton Trolley Locomomtive | |||
Model | CJY14/6、7、9G(B)(P) | ||
Adhesive / total weight (t) | 14t | ||
Track gauge (mm) | 600、762 or 900mm | ||
Traction | 26.68kN | ||
Max. Traction (KN) | 34.3kN | ||
Speed | 12.87km/h | ||
Direct Voltage | 250V | 550V | |
motor power | 52kW×2 | ||
Dimensions | Length | 4800mm | |
Width | 1060、1222 or 1360mm | ||
Height | 1700mm | ||
Wheel Base | 1700mm | ||
Wheel Diameter | 760mm | ||
Operational height of current-controller | 2000～3200mm | ||
Min Curve radius (m) | 12m | ||
Controller | Resistance or IGBT | ||
Braking method | Air, Mechanical Brake | ||
