1. Product Model explanation and loading capacity
CTY10/6GB refer to the mining 10 Ton electric battery locomotive and the track gauge be 600mm the loading capacity could up to 80-90 Ton ores.
2. Questions before inquiry
Controller: Cam Chopping or frequency conversion controller
Track gauge: 600.762.900 different track gauge could design as required
Brake method: Mechnical or Air brake
Locomotive Avantage Please Click: Locomotive Advantages.
Operation video
Coal mine explosion-proof electric locomotive refers to the rail transportation electric locomotive used for coal mine transportation. This kind of electric locomotive is usually an explosion-proof special battery electric locomotive. It uses an explosion-proof lead-acid power supply or a maintenance-free power supply as the power source to drive the electric locomotive.
Its electrical components including motors, LED lights, speakers, controllers, and power supplies are all explosion-proof special enclosures to avoid explosions.
Technical Specification
Model | CTY(L)10/6、7、9G | ||||||
Dead-weight | 10 t | ||||||
Track gague | 600、762 or 900mm | ||||||
Tracktion force | 11.18kN | 12.83kN | |||||
Speed | 6.2km/h | 7.5 km/h | 7.8 km/h | ||||
Max traction | 19.62kN | ||||||
Battery device | Voltage | 110V | 132V | 140V | 144V | ||
Capacity | 440Ah | ||||||
Motor power | 11kW×2 | 15kW×2 | |||||
dimensions | Lenght | 4430mm | 4250mm | ||||
Width | 1050、1212 or 1350mm | ||||||
Height | 1600mm | 1600mm | |||||
Wheel base | 1100mm | 1150mm | |||||
Wheel diameter | Φ680mm | Φ680mm | Φ600mm | ||||
Min turn radius | 7m | ||||||
Controlling way | Resistence or IGBT or AC Converter | ||||||
Brake way |
Mechnical brake or air brake |
