China 6 Ton Explosion-proof battery locomotive

6 Ton Explosion-proof Battery Locomotive is ususally Applied in coal mining or tunnel for transporating ores, people and other things. Battery can be choosed as lithium battery or lead-acid battery, and can be applied of hydraulic braking or air brak

CJY10 Ton Underground Mining Trolley Locomotive
6 Ton Explosion-proof Battery Locomotive is ususally Applied in coal mining or tunnel for transporating ores, people and other things.
Battery can be choosed as lithium battery or lead-acid battery, and can be applied of hydraulic braking or air braking according to the requirements,which make the locomotive have both hydraulic brake  and mechanical braking funtion. Its safe and reliable performance makes it very popular.


Locomotive Avantage Please Click: Locomotive Advantages.


Operation video


Model CTY6/679G(B)
Total-weight 6t
Track gague 500600762 or 900mm
Tracktion force 7.06kN
Max traction 12.26kN
Speed 7km/h
Battery device Voltage 90V
Capacity 385Ah
Motor power 7.5 kW×2
dimensions Lenght 3170mm
Width 9201082 or 1220mm
Height 1550mm
Wheel base 850mm
Wheel diameter Φ520mm
Min turn radius 6m
Controlling way Resistence or IGBT
Brake way Mechnical brake or hydraulic
