1. Introduction of product model
CAY 5/6,7,9GB(P)
CAY: battery powered electric locomotive
2.5: Means the locomotive weight 5 Ton
5,6,7,9: Means the track gauge could be choose in 500, 600,762 or 900
The traction of a 5-ton battery electric locomotive is about 50 tons on a slope of 3‰ (need to reduce the weight of the locomotive), that is 45 ton ores
2. What should know before make a inqury?
1.Do you need Normal type or flameproof type
If it is in a coal mining with gas, that means the locomotive should be flameproof. Ordinary type can be applied the places without gas.
2. Gauge selection: standard gauges are usually with 600, 762 and 900, and different gauges can be customized according to requirements.
3. Controller Method: resistance, IGBT, frequency controller and remote control.
4. Battery Device: lead-acid battery (both ordinary and explosion-proof type), maintenance-free battery (both ordinary and explosion-proof type), lithium battery (ordinary type). Lithium batteries are maintenance-free and have a long service life. The service life is about 5 times that of ordinary lead-acid batteries.
5. Selection of braking methods: mechanical braking, hydraulic braking.
6. If you don’t know how to select, you can provide mine humidity, dust, transportation distance, number of bends, load weight, working hours of a shift, working height and other specific working conditions so that we can help you choose the most suitable Battery Electric locomotive.
Locomotive Avantage Please Click: Locomotive Advantages.
Operation Video:
We provide flameproof locomotive with CE certification. Our factory has specialized in mining locomotive for many years,covering the market in South America and Africa. Hoping to start stable and long-term business relationship to you.
←China 500mm rail gauge 5 Tons battery operated locomotive with hydraulic brake
Explosion-proof 18 inch track gauge 5TN battery operated locomotive Factory→
Model | CTY5/6、7、9G(B) | |||
Total-weight | 5t | |||
Track gague | 500、600、762 or 900mm | |||
Tracktion force | 7.06kN | |||
Max traction | 12.26kN | |||
Speed | 7km/h | |||
Battery device | Voltage | 90V | ||
Capacity | 385Ah | |||
Motor power | 7.5 kW×2 | |||
dimensions | Lenght | 3170mm | ||
Width | 920、1082 or 1220mm | |||
Height | 1550mm | |||
Wheel base | 850mm | |||
Wheel diameter | Φ520mm | |||
Min turn radius | 6m | |||
Controlling way | Resistence or IGBT | |||
Brake way | Mechnical brake or hydraulic |
