China 600mm rail gauge 3TN battery operated locomotive Pricelist

China 1. Introduction Of Product Model CAY 3/6,7,9GB(P) CAY: Mining battery powered electric locomotive 3: Means the locomotive weight 5 Ton 5,6,7,9: Means the track gauge could be choose in 500, 600,762 or 900 or designed as your need The traction of a 5- Pricelist

CJY10 Ton Underground Mining Trolley Locomotive
We supply explosion-proof locomotive with CE certification and factory price. Our factory has specialized in mining locomotive for more than 40 years, exported to South America and Africa. Hoping to start business with you soon.



1. Introduction Of Product Model
CAY 3/6,7,9GB(P)
CAY:Mining battery powered electric locomotive
3: Means the locomotive weight 5 Ton
5,6,7,9: Means the track gauge could be choose in 500, 600,762 or 900 or designed as your need
The traction of a 5-ton battery electric locomotive is about 30 tons on a slope of 3‰ (need to reduce the weight of the locomotive), that is 25 ton ores


2. What Should Know Before Make A Inqury?
1.How do i know if i need normal type or explosion-proof type?
Coal mining with gas, the locomotive will need explosion-proof, others normal type ifs ok
2. Gauge selection: standard gauges are usually with  600, 762 and 900, and different gauges can be customized according to requirements.
3. Controller Method: Cam controller, IGBT, frequency controller and remote control.
4. Battery Device: lead-acid battery (both ordinary and explosion-proof type), maintenance-free battery (both ordinary and explosion-proof type), lithium battery (ordinary type). Lithium batteries are maintenance-free and have a long service life. The service life is about 5 times that of ordinary lead-acid batteries.
5. Selection of braking methods: mechanical braking, hydraulic braking.
6. If you do not know how to select, you can provide mine humidity, dust, transportation distance, number of bends, load weight, working hours of a shift, working height and other specific working conditions so that we can help you choose the most suitable Battery Electric locomotive.
Locomotive Avantage Please ClickLocomotive Advantages.

Operation Video:



The battery mine electric locomotive has no risk of spark detonation, and is suitable for use in mines with gas; it does not require wiring and is flexible in use, and is very suitable for transportation systems with small output and irregular roadways and roadway excavation transportation. However, charging equipment must be installed; the initial investment is large; the electricity consumption efficiency is low, and the transportation cost is high.



Technical Specification

                                                                                                                     Model CTY3/679G(B)
Dead weight 2.5t
Track gauge 600762 or 900mm
Traction force 2.55kN
Max traction force 6.13kN
Speed 4.54km/h
Battery device Lithium battery 51.2v 300ah
Lead acid battery 48V330AH
Motor power 3.5kW×1
Dimensions Length 2330mm
width 9141076 or 1212mm
Height 1550mm
Wheelbase 650mm
Wheel diameter Φ460mm
Min turn radius 5m
Controlling way Resistance or IGBT chopper
Brake way Mechanical brake
