CAY2.5/6G Battery Powered 2.5 Ton Locomotive

Product Introduction CAY2.5/6G Means the battery powered locomotive weight 2.5 ton and track gauge be 600mm, the controller method is resitance controller. It has 2 types, normal type and anti-explosion type, normal type is usually applied in the met

Send Inquiry →

CJY10 Ton Underground Mining Trolley Locomotive

Product Details
Technical Parameters

Product Introduction
CAY2.5/6G Means the battery powered locomotive weight 2.5 ton and track gauge be 600mm, the controller method is resitance controller.
It has 2 types, normal type and anti-explosion type, normal type is usually applied in the metal minings such as copper, gold, zinc and ect. While the anti-explosion type is applied in the coal mining or places with gas.

The traction force of a 2.5 ton locomotive could be about 25 Ton ores,which should be caculated the self-weight of locomotive and wagons.

Lithium battery could be as a option of this type locomotive,0 pollution and maintenance-free. Quick charging, labor cost saving

Operation Video:

←15 Ton Battery Locomotive(CTY15/6GB)

CAY5/6,7,9G 5 Ton Mine Battery Powered Electric locomotive→

Related Product

Technical Specification

Model			CTY2.5/6、7、9G(B)
Dead weight			2.5t
Track gauge			600、762 or 900mm
Traction force			2.55kN
Max traction force			6.13kN
Speed			4.54km/h
Battery device		Lithium battery	51.2v 300ah
		Lead acid battery	48V330AH
Motor power			3.5kW×1
Dimensions	Length		2330mm
	width		914、1076 or 1212mm
	Height		1550mm
	Wheelbase		650mm
	Wheel diameter		Φ460mm
Min turn radius			5m
Controlling way			Resistance or IGBT chopper
Brake way			Mechanical brake
