Structure of Remote Control Rock Loader
1. The orginal two electric control boxes have become one and another place has been replaced with hydraulic device. A set of Hydraulic motors is added between turntable and tray driving turntable rotating.
2. Via a set of remote controller the machine can be remote-controlled operation.
Featurs of Remote Control Rock Loader
1. Long distance(between 5m-20m) keeps operators from dangers.
2.Opereator are relived from tedious labor with the enhancement of working enviroment.
3.Efficiency is enhanced by above 30% as for its visual operation.
4.Lighting device is added in head of the machine with three modes : remote control button control back up control.
Operation Video
Shipment and one site details
Specification
| Model | Z-17AW | Z-20AW | Z-30AW | ZQ-26 | ||
| Loading capacity m3/h | 20-30 | 30-40 | 50-60 | 40-50 | ||
| Loading area m3 | 0.17 | 0-20 | 0.3 | 0.26 | ||
| Loading width m | 1.7 | 2 | 2.2 | 2.7 | ||
| Track gauge mm | 500600762 or 900 | |||||
| Power | Motor | Motor | Motor | Wind motor | ||
| Walking power kw | 10.5 | 10.5 | 15 | 10.5 | ||
| Lifting bucket power KW | 10.5 | 13 | 15 | 15 | ||
| Unloading height mm | 10.5 | 1360 | 1370 | 1250 | ||
| Dimension mm | Length | 2120 | 2480 | 2620 | 2440 | |
| Width | 1011 | 1380 | 1320 | 1380 | ||
| Height | 1920 | 1460 | 1545 | 1500 | ||
| Weight | 3760 | 3700 | 4600 | 2700 | ||
