Metal Mine applicated The pneumatic rocker shovel loader use air as the power source to supply the machine work. It has a range application such as in me<x>tal mines coal mines and with great working efficiency. technical specification
The pneumatic rocker shovel loader use air as the power source to supply the machine work.
It has a range application such as in me
It is a single-bucket orbital rock loader that directly unloads. Its main purpose is to load the rock and ore from the blasting caving in the mine cart.
It can also be used to load rocks and coal in the open air. Blocks limestone or sand etc. which to realize the mechanization of loading work.
The application work surface should be 1.8*2.5m.
With the optimal design of the transducer machine, the electric rock loader has a more reasonable structure, stronger stability, more convenient operation, safer running, and higher efficient deslagging. The bucket bottom is alloy wear resistant material with high durability and long service life.
←Tunnel application 600mm track gauge 50m3/h loading capacity wheel type mucking machine quotation
Flame-proof 600mm track gauge 60m3/h loading capacity wheel type mucking machine Price→
Specification Table
| Model | Z-17AW | Z-20AW | Z-30AW | ZQ-26 | ||
| Loading capacity m³/h | 20-30 | 30-40 | 50-60 | 40-50 | ||
| Loading area m³ | 0.17 | 0-20 | 0.3 | 0.26 | ||
| Loading width m | 1.7 | 2 | 2.2 | 2.7 | ||
| Track gauge mm | 500600762 or 900 | |||||
| Power | Motor | Motor | Motor | Wind motor | ||
| Walking power kw | 10.5 | 10.5 | 15 | 10.5 | ||
| Lifting bucket power KW | 10.5 | 13 | 15 | 15 | ||
| Unloading height mm | 10.5 | 1360 | 1370 | 1250 | ||
| Dimension mm | Length | 2120 | 2480 | 2620 | 2440 | |
| Width | 1011 | 1380 | 1320 | 1380 | ||
| Height | 1920 | 1460 | 1545 | 1500 | ||
| Weight | 3760 | 3700 | 4600 | 2700 | ||
