Coal mine applicated 100m³loading capacity wheel scraper mucking loader suppliers

Coal mine applicated The wheel scraper mucking loader is suitable for large medium and small roadways with a working section of 2.4*2.4m or more and a slope of about 12. Mainly used in coal mines and non-coal mines water diversion tunnel projects and urban pipe network suppliers

CJY10 Ton Underground Mining Trolley Locomotive
Mucking Loader also called hag-loader or excavating loader, is a kind of underground projects machinery typically used in the excavating of tunnel mining, mine engineering, coal mines, metal mines, hydropower tunnels and hydraulic engineering. According to the different transportation modes, mucking loader can also be divided into crawler mucking loader and tyre mucking loader.


The wheel scraper mucking loader is suitable for large medium and small roadways with a working section of 2.4*2.4m or more and a slope of about 12°. Mainly used in coal mines and non-coal mines water diversion tunnel projects and urban pipe network tunneling and loading operations. The working principle is to excavate and transport various ore and slag materials and directly load them into wagons agricultural vehicles or other transportation equipment. It greatly improves work efficiency and is an ideal mechanized slagging equipment for mines and tunnels.
This series of slag scraper adopts four-wheel drive thick chain high and low scraper conveying and the integral conveying trough body welded by high-strength steel plate. The service life and effect are much higher than that of belt conveying. This model is the price of a wheeled machine and the function of a scraper machine achieves high quality and low cost. The structure is compact the driving force is large the picking range is wide the lifting positioning is accurate the material transportation speed is fast and the rock can be loaded in a comprehensive section without leaving dead corners. No need for manual assistance to clean up the working surface.



















Mucking loader, also known as excavating loader, is combined the manipulator with conveyor. The mucking loader is equipped with grilled slag and transport loading function. It adopts the electric full hydraulic control system and production equipment, which has the characteristics of safety, environmental protection, low energy consumption and high efficiency.
