Tunnel application 600mm rail gauge 3tons elelctri trolley locomotive quotation

Tunnel application This 3 ton electric locomotive is generally suitable for small mines as auxiliary transportation tools or main traction transportation tools. quotation

CJY10 Ton Underground Mining Trolley Locomotive
We could customized huge tonne mining trolley locomotive according different mine environment with CE certification. Our factory has specialized in mining locomotive for many years,exported lots of locomotive to South America and Europe in these years. We are looking forward to start business relationship with you.
1. Product Model And Traction Analysis(3 Ton Electric Trolley Mining Locomotive )

CJY3/679GB(P)

CJY: Trolley electric locomotive for mine

3: Indicates that the weight of the electric locomotive is 3 tons

6,7,9: Indicates that the gauge is divided into three types: 600,762,900 or as requirement

GB(P): G means resistance speed regulation GB means chopping speed regulation GP means frequency conversion speed regulation

The normal traction force of a 3-ton overhead electric locomotive is about 30 tons on a slope of 3‰ (need to subtract the weight of the locomotive)

2. Introduction To Electric Locomotive

Electric Trolley locomotives are mainly used for rail transportation in mines or tunnels and are mainly used to haul mine carts flatbed carts or man-cars for the transportation of ore manpower or materials. This 3 ton electric locomotive is generally suitable for small mines as auxiliary transportation tools or main traction transportation tools.

3. Inquiry Notice

1. Gauge selection: standard gauges are generally 600 762 and 900 and different gauges can be customized according to requirements.

2. Speed regulation mode: resistance chopping frequency conversion and remote control are four options.

3. DC voltage: 250V or 550V

4. Selection of braking methods: mechanical braking hydraulic braking and air braking.

5. If you don’t know how to choose the model you can provide the Transportation Distance, The Number Of Curves ,The Loading Capacity, The Working Time Of A Shift, the Working Height And Other Specific Working Conditions so that we can help you choose the most suitable electric locomotive.

Locomotive Avantage Please ClickLocomotive Advantages.

4.Video



The overhead electric locomotive must have rectification and overhead wiring facilities, which is not flexible enough; the overhead wiring has a certain impact on the size of the roadway and the safety of pedestrians; it is easy to generate sparks between the pantograph and the overhead wiring, and it is not allowed to be used in mines with severe gas. ; The initial construction investment is relatively large, but in the long run, the total cost of using a wire electric locomotive is much lower than that of a battery electric locomotive. Therefore, if the mine conditions permit, the main transportation of the mine should be by wire electric locomotives.




Model CJY3/679G(B)
Weight 3 ton
Track gauge 600762 or 900mm
Traction force 5.74kN
Max traction force 7.36kN
Speed 7.5km/h
Dc voltage 250V
Motor power 6.5kW×2/ 7.5kw*2
Dimensions Length 2750mm
Width 9401082 or 1220mm
Height 1550mm
Wheelbase 850 mm
Wheel diameter Φ520 mm
working height of Pantograph 1800~2000mm
Min turn radius 6m
Control method Resistance or IGBT
Brake method Mechnical or hydraulic
