Metal Mine applicated 10 Ton Mining Electric Trolley Locomotive the model is CJY10/679GB. It has 4 options: normal type thicken lateral plate type added sails type and 2 motors type. The working rated voltages include 250v and 550v Main features include:short wheel Technical parameters
(1) Use gradient: the general gradient is 3‰
(2) Is it explosion-proof? It must be explosion-proof in coal mines
(3) Power supply option: trolley, battery or lithium battery, lithium battery is environmentally friendly and maintenance-free.
(4) Speed regulation mode: resistance, chopper or frequency conversion
(5) Braking method: mechanical brake or hydraulic brake, the hydraulic brake has a short braking distance and is safer.
(6) Gauge: 600, 762, 900mm or others
10 Ton Mining Electric Trolley Locomotive the model is CJY10/679GB. It has 4 options: normal type thicken lateral plate type added sails type and 2 motors type.
The working rated voltages include 250v and 550v Main features include:short wheel base and high stiffness of locomotive body.
With Application of new-type buffer the shockproof performance is good with big cushion angle.
Motor power: 24kw*2 or 30kw*2
Track gauge: 600.762.900 or as required
Carrying capacity: 100 Ton
Voltage:250V or 550V
Locomotive Avantage Please Click: Locomotive Advantages.
Operation Video
We could offers durable narrow gauge mining trolley locomotive with CE certification and factory price. Our factory has specialized locomotive for many years, got good feedback from South America and Europe. Hoping to start business relationship with you soon.
←buy discount 20 inch rail gauge CJY10 Overline electric locomotive manufacturers
Factory directly sell 24 inch rail gauge k10 elelctri trolley locomotive with hydraulic brake→
10ton Trolley Locomotive | |||
Model | CJY10/6、7、9G(B)(P) | ||
Adhesive / total weight (t) | 10t | ||
Track gauge (mm) | 600、762 or 900mm | ||
Traction | 13.05kN | 18.93kN | |
Max. Traction (KN) | 24.5kN | ||
Speed | 11km/h | ||
Direct Voltage | 250V | 550V | |
motor power | 24Kw×2 | 30kW×2 | |
Dimensions | Length | 4550mm | |
Width | 1050、1212 or 1350mm | ||
Height | 1600mm | ||
Wheel base | 1100、1220mm | ||
Wheel Diameter | Φ680mm | ||
Operational height of current-controller | 1800~2200mm、2000~2400mm | ||
Min Curve radius (m) | 7、10m | ||
Controller | Resistance or IGBT | ||
Braking method | Mechanical Brake |
