China 750mm rail gauge CJY7 cable wire locomotive Price

China The 7 Ton Electric Trolley Locomotive has 2 kinds of working rated voltage: 250V or 550V. It applies primary driving way speed control of resistance IGBT or VF type. Main features include: short wheel base high sitffness body and good shickproof Price

Send Inquiry →
CJY10 Ton Underground Mining Trolley Locomotive
Mining electric locomotives are divided into overhead electric locomotives, battery electric locomotives, lithium battery electric locomotives, and dual-power electric locomotives. It is mainly transported by rail, underground or roadway.
The 7 Ton Electric Trolley Locomotive has 2 kinds of working rated voltage: 250V or 550V. It applies primary driving way speed control of resistance IGBT or VF type. Main features include: short wheel base high sitffness body and good shickproof performacee.
The braking type is mechanical or electric braking or air braking safe and reliadble.
The carrying loading capacity of 7 Ton trolley locomotive could up to 70 ton.

Motor power: 21kw *2
Voltage :250 v or 550v
Track gauge: 600.750.762.900 or as required.

Locomotive Avantage Please Click: Locomotive Advantages.

Operation video


Durable diesel locomotive for mine with durable quality for sale. The costs of diesel locomotive lower than battery and trolley locomotive, hoping to holding business cooperation with you.


Hot Tags: mining locomotive  |   battery locomotive  |   trolley locomotive  |   electric rake winch  |   pneumatic Rock loader  |

←buy discount 750mm rail gauge CJY7 cable wire locomotive with hydraulic brake

China 750mm rail gauge CJY7/6GB Overline electric locomotive with Air brake→

Related Product



7ton Trolley Locomotive

Model

CJY7/6、7、9G(B)(P)

Adhesive / total weight (t)

7t

Track gauge (mm)

600、762 or 900mm

Traction

13.05kN

15.09kN

Max. Traction (KN)

17.2kN

Speed

11km/h

Direct Voltage

250V

550V

motor power

21Kw×2

24kW×2

Dimensions

Length

4550mm

Width

1050、1212 or 1350mm

Height

1600mm

Wheel Base

1100mm

Wheel Diameter

Φ680mm

Operational height of current-controller

1800~2200mm

Min Curve radius (m)

7m

Controller

Resistance or IGBT

Braking method

Mechanical Brake
